Hydraulic Press

FUKUI JAPAN
MODEL: 500
SKU # HM 0381

Brief Specifications/ Details

• Cap: 500Tons
• Stroke: 1000mm
• Bed: 2700 x 1520mm
• Ram: 2700 x 1520mm
• Day Light: 1500mm
• Down Speed: 350mm/sec
• Pressing Speed: 46~32mm/sec
• Return Speed: 350mm/sec

Accessories

• With Die Cushion
• Cushion Tonnage: 300T
• Cushion Stroke: 400T
• Cushion Area: 2200 x 950mm

Other Details (Approx)

• Power Required : V/ KVA Phase:
• Main Motor : 110kw
• Air Required : 206kg/sqcm
• Working Space : F-B: ’-”, L-R: ’-”, HT: ’-”
• Packing Size : F-B: ’-”, L-R: ’-“, HT: ’-”
• Net Weight : Tons
