KOJIMA JAPAN
HYDRAULIC PRESS
KOJIMA JAPAN
SKU # HM 0405
Brief Specifications/ Details
- Cap.: 500t
- Regular pressure: 200kg/cm3
- Main ram diameter: 40 mm Φ x 2
- Stroke: 1300mm
- Day light: 1800mm
- Bolster size: 3000 x 2000mm
- Ascending capacity: max 57t (135mm Φ x 2)
- Descending speed: 250~300 mm/sec
- Ascending speed: max 280 mm/sec
Accessories
- Die cushion Cap.: 200t (during low pressure is 160kg/cm3)
- Ascending Cap.: 15~75t (during 60 kg/cm3)
- Ram dia x No.: 180 mmΦ x 5
- Stroke: 400mm
- Pad area: 2800 x 1580mm
- Descending speed: Self weight drop approx 50 mm/sec
- Weight of the press: approx 100t
