SAMHO KOREA MODEL : SHC-200
C FRAME SINGLE CRANK PRESS
SAMHO KOREA
MODEL : SHC-200
SKU # 1829
Brief Specifications/ Details
- Cap : 200Tons
- Stroke : 250mm
- Die Height : 500mm
- Adjustment : 110mm-Electrical
- SPM : 30~45
- Slide : 1150 x 750mm
- Bolster : 1450 x 850mm
Accessories
- With Die Cushion and Dry clutch
- Pad Area – 450 x 260mm
Other Details (Approx)
- Clutch : Dry
- Main Motor : 22KW
- Power Required : 380V/27KVA Phase : 3
- Air Required : 5.5/sqcm
- Machine Size : F-B: 8’-5”, L-R: 6’-9”, HT: 14’-0”
- Machine Weight : 22Tons
