SSANGYONG KOREA MODEL : CS -150
C FRAME SINGLE CRANK PRESS
SSANGYONG KOREA
MODEL : CS -150
SKU # 1808
Brief Specifications/ Details
- Cap : 150Tons
- Stroke : 250mm
- Die Height : 450mm
- Adjustment : 100mm-Electrical
- SPM : 35~50
- Slide : 1000 x 580mm
- Bolster : 1350 x 760mm
Accessories
- With Die Cushion
Other Details (Approx)
- Clutch : Wet
- Main Motor : 18 KW
- Power Required : 380V/22KVA Phase : 3
- Air Required : 5.5/sqcm
- Machine Size : F-B: 7’-5”, L-R: 5’-5”, HT: 12’-9”
- Machine Weight : 16Tons
