WASINO JAPAN MODEL : PUX-35
C FRAME SINGLE CRANK PRESS
WASINO JAPAN
MODEL : PUX-35
SKU # 1723
Brief Specifications/ Details
- Cap : 35Tons
- Stroke : 90mm
- Die Height : 240mm
- Adjustment : 55mm
- SPM : 80
- Slide : 380x 300mm
- Bolster : 710x 380mm
Other Details (Approx)
- Clutch : Dry
- Main Motor : 3.7KW
- Power Required : 220V/4KVA Phase : 3
- Air Required : 5.5/sqcm
- Machine Size : F-B: 5’-2”, L-R: 3’-9”, HT: 8’-5”
- Machine Weight : 3 Tons
