AIDA JAPAN MODEL : C1-4(2)
C FRAME SINGLE CRANK PRESS
AIDA JAPAN
MODEL : C1-4(2)
SKU # 1775
Brief Specifications/ Details
- Cap : 45Tons
- Stroke : 140mm
- Die Height : 300mm
- Adjustment : 60mm
- SPM : 50~90
- Slide : 410 x 340mm
- Bolster : 830 x 470mm
Accessories
Other Details (Approx)
- Clutch : Dry
- Main Motor : 3.7 KW
- Power Required : 220V/4.5KVA Phase : 3
- Air Required : 5.5/sqcm
- Machine Size : F-B: 5’-0”, L-R: 4’-3”, HT: 7’-5”
- Machine Weight : 4 Tons
