AIDA JAPAN MODEL : NC1-110(2)
C FRAME SINGLE CRANK PRESS
AIDA JAPAN
MODEL : NC1-110(2)
SKU # 1816
Brief Specifications/ Details
- Cap : 110Tons
- Stroke : 180mm
- Die Height : 350mm
- Adjustment : 90mm-Electrical
- SPM : 35~65
- Slide : 630 x 520mm
- Bolster : 1070 x 680mm
Accessories
- With Die Cushion
- Pad Area – 270 x 270mm
Other Details (Approx)
- Clutch : Wet
- Main Motor : 7.5 KW
- Power Required : 220V/9KVA Phase : 3
- Air Required : 5.5/sqcm
- Machine Size : F-B: 7’-0”, L-R: 4’-5”, HT: 10’-5”
- Machine Weight : 10.5Tons
