DONGSHIN KOREA MODEL : DS-110P
C FRAME SINGLE CRANK PRESS
DONGSHIN KOREA
MODEL : DS-110P
SKU # 1818
Brief Specifications/ Details
- Cap : 110Tons
- Stroke : 160mm
- Die Height : 415mm
- Adjustment : 100mm
- SPM : 35~50
- Slide : 810 x 510mm
- Bolster : 1200 x 660mm
Other Details (Approx)
- Clutch : Dry
- Main Motor : 11KW
- Power Required : 380V/13KVA Phase : 3
- Air Required : 5.5/sqcm
- Machine Size : F-B: 7’-0”, L-R: 5’-4”, HT: 12’-0”
- Machine Weight : 11 Tons
