C FRAME SINGLE CRANK PPRSS

HANOUL KOREA

MODEL : HNCP-160

SKU # 1953

Brief Specifications/ Details

• Cap : 160tons
• Stroke : 200mm
• Die height : 445mm
• Adjustment : 100
• SPM : 35~50
• Slide : 1000 x 700mm
• Bolster : 1300 x 800mm

Accessories

• With Die Cushion
• Pad Area – 375 x 225mm

 Other Details (Approx)

• Clutch : Dry
• Main Motor : 11 KW
• Power Required : 380V/13KVA Phase : 3
• Air Required : 5.5/sqcm
• Machine Size : F-B: 8’-11”, L-R: 5’-6”, HT: 11’-6”
• Machine Weight : AP – 16 Tons
