AIDA JAPAN MODEL : NC1-8(2)B
C FRAME SINGLE CRANK PRESS
AIDA JAPAN
MODEL : NC1-8(2)B
SKU # 1696
Brief Specifications/ Details
- Cap : 80Tons
- Stroke : 160mm
- Die Height : 320mm
- Adjustment : 80mm-Electrical
- SPM : 40~75
- Slide : 540 x 460mm
- Bolster : 950 x 600mm
Accessories
With Die Cushion
Other Details (Approx)
- Clutch :
- Main Motor : KW
- Power Required : 220V/10KVA Phase : 3
- Air Required : 5.5/sqcm
- Machine Size : F-B: 7’-0”, L-R: 4’-10”, HT: 9’-0”
- Machine Weight : Tons
