WASINO JAPAN MODEL : PUX-100
C FRAME SINGLE CRANK PRESS
WASINO JAPAN
MODEL : PUX-100
SKU # 1707
Brief Specifications/ Details
- Cap : 100Tons
- Stroke : 180mm
- Die Height : 350mm
- Adjustment : 80mm
- SPM : 50
- Slide : 600x 450mm
- Bolster : 1020x 600mm
Accessories
With Die Cushion
Other Details (Approx)
- Clutch : Dry
- Main Motor : 7.5KW
- Power Required : 220V/9.5KVA Phase : 3
- Air Required : 5.5/sqcm
- Machine Size : F-B: 7’-0”, L-R: 4’-5”, HT: 11’-5”
- Machine Weight : Ap 10 Tons
