AMADA JAPAN MODEL : TP-25C-X
C FRAME SINGLE CRANK PRESS
AMADA JAPAN
MODEL : TP-25C-X
SKU # 1718
Brief Specifications/ Details
- Cap : 25Tons
- Stroke : 80mm
- Die Height : 220mm
- Adjustment : 50mm
- SPM : 110
- Slide : 250x 200mm
- Bolster : 550x 300mm
Accessories
Other Details (Approx)
- Clutch : Dry
- Main Motor : 5.5 KW
- Power Required : 220V/2.6KVA Phase : 3
- Air Required : 5.5/sqcm
- Machine Size : F-B: 4’-0”, L-R: 3’-5”, HT: 7’-5”
- Machine Weight : 1.5Tons
